Description
Manufacturer OEM Number:
AC166
95176
C95176
AC166
92061898
4030011
ADG074209
556117B
556117HQ
2H1084
SK0013
84062
15306
25392
Warranty: 3 Years
Application:
CHEVROLET REZZO (2005/03 - /)
CHEVROLET EVANDA (2005/03 - /)
DAEWOO NUBIRA (KLAJ) (1997/04 - /)
DAEWOO NUBIRA Wagon (KLAJ) (1997/04 - /)
DAEWOO LEGANZA (KLAV) (1997/06 - 2004/04)
DAEWOO NUBIRA Saloon (KLAJ) (1997/04 - /)
DAEWOO REZZO (KLAU) (2000/09 - /)
DAEWOO EVANDA (KLAL) (2002/08 - /)
DAEWOO NUBIRA Saloon (KLAN) (2003/07 - /)
DAEWOO NUBIRA Wagon (KLAN) (2003/07 - /)
TECHNICAL PARAMETER:
Operateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
