Description
Manufacturer OEM Number:
90120 390120 F01R065901 53030657
53009735 53030450 53030657AB
Replaces dealer part numbersr:
53030450 53030657 53030657AB 53030657AC AC68 CV10155 5003467AA
21821 217204 217-204 IAC34 53009735 17119277 AC305 IAC34 2H1091
Warranty: 3 Years
Aplication:
for Chery QQ F3 473QE six -generation V19
Technical Parameter:
Oeperateing Temperature Range:-40℃-125℃(150℃ peak)
Nominal Operating Voltage:12VDC
MIN/MAX Operating Voltage:7.5V-14VDC
Resistance Per Winding (@25℃):53Ω±10%
Minimum Resistance (@-40℃):35Ω
Solenoid inductance:33mH±20%
Step Increment :0.04167mm
MAX travel:8.5mm(204step)
